PA210 Premium Tap Base Pillow Block Housing

$148.81



Australia-Wide Flat Rate Shipping

$12 Standard Shipping – Australia Post eParcel service (Check Australia Post for transit times to your location)
$35 Courier Service – Courier Service for greater traceability and faster delivery

Select your preferred option at the checkout

*Flat-Rate shipping excludes large/bulky items, consignment weights over 21kg, dangerous goods and remote areas.  Freight charge will be calculated and added to your invoice after your order is placed or please request a quote first*
SKU PA210-PRM
Brand Asahi
Shipping Weight 1.8200kg
Grade Premium
Max. Operating Temperature (deg. C) +120°C
Min. Operating Temperature (deg. C) ­20°C
Housing Type Tap Base Pillow Block Housing
Housing Material Cast iron
Number Of Mounting Holes 2
(l) Length (mm) 130
(a) Width (mm) 64
(j) Hole Centres (mm) 94
(h) Height To Centre Of Shaft (mm) 57.2
(h²) Overall Height (mm) 113
Thread Size M16X2.00
