ITM Electric Chain Hoist, 415V, 5 Tonne, 3 Meter Lift

$4,999.01



Large and/or Heavy Item

Australia-Wide Flat Rate Shipping

$12 Standard Shipping – Australia Post eParcel service (Check Australia Post for transit times to your location)
$35 Courier Service – Courier Service for greater traceability and faster delivery *NO PO BOXES*

Select your preferred option at the checkout

*Flat-Rate shipping excludes large/bulky items, consignment weights over 21kg, dangerous goods and remote areas.  Freight charge will be calculated and added to your invoice after your order is placed or please request a quote first*
  • Japanese technology with dual braking system to ensure safe and reliable operation
  • Dual Speed
  • Compact and light weight design
  • Weight overload limiter for safety
  • Dual-gear drive system providing smooth and quiet operation
  • Three phase, 415V motor
  • Upper and lower limit switches to prevent chain runout
  • Chain length can be altered by ITM to your required length
  • Tested & certified to AS 1418.2
  • Test certificate & user manual supplied
  • Replacement Chain 7.1mm TM9810-01607-1
  • Replacement Chain 11.2mm TM9810-04011-2
  • Rated Capacity: 5 Tonne
  • Standard Lift: 3m
  • Running Test Load: 62.5kN
  • Motor: 3000W 415V 3P
  • No. of Chain Drops: 2
  • Chain Type: Grade 80 11.2mm
  • Lift Speed: 2.7 & 0.9m/min
  • Net Weight: 151kg
  • Extra Weight Per Metre Of Extra Lift: 5.6kg
  • Dimension A: 670mm
  • Dimension B: 313mm
  • Dimension D: 430mm
  • Dimension E: 325mm
  • Dimension H: 1030mm
  • Dimension I: 60mm
  • Dimension J: 48mm
  • Dimension K: 60mm
  • Dimension L: 48mm
  • Dimension M: 43mm
  • Dimension N: 43mm
SKU TM9003-05003
Barcode # 9328042036179
Brand ITM
Shipping Weight 149.0000kg
