76 Tooth BS Sprocket 12B 3/4 Inch Pitch Simplex Taper Lock Centre

$666.30



Australia-Wide Flat Rate Shipping

$12 Standard Shipping – Australia Post eParcel service (Check Australia Post for transit times to your location)
$35 Courier Service – Courier Service for greater traceability and faster delivery

Select your preferred option at the checkout

*Flat-Rate shipping excludes large/bulky items, consignment weights over 21kg, dangerous goods and remote areas.  Freight charge will be calculated and added to your invoice after your order is placed or please request a quote first*
SKU 12B-1-76TL
Shipping Weight 11.6800kg
Bore Taper Lock
Compatible Bush 2517
(P) Pitch (mm) 19.05 (3/4")
Sprocket Material Steel
No. Of Teeth 76
No. Of Rows 1
(B¹) Tooth Width (mm) 11.1
(de) Outside Ø (mm) 471.1
(dp) Pitch Ø (mm) 461
(dm) Hub Ø (mm) 108
(A) Sprocket Width (mm) 44.45
Sprocket Type Type 1
